BT 6080
ECOGRACE
6788900
Filter Press Filter cloth , Sludge dewatering belt are designed for solid/ liquid separation, especially for sludge dehydration in sewage treatment. Made of high quality Polyester Fabric , our range of filter fabrics is heat-set at exacting temperature and tensioned to achieve much better operational stability. It is suitable for press belt filter and various vacuum belt filters.
Polyester sludge dewatering belt with smooth surface and air permeability, is recommended for most sludge dewatering plants.
Filtration Belt cloth is mainly applied to Belt filter press , vacuum Belt Press . The width of belt 1-4 meter , length as customer required. Both the woven fabrics and Non woven felt filtration belt are available.
The main industries we are serving is Mineral , Chemical , Food processing , FGD , Material Dehydration, liquid and solid separation .
Advantages of ECOGRACE Belt Filter Fabric :
Strong structure with high drainage speed.
Excellent water and air permeability without sludge leaking.
Good at resistance to acid, alkali and chemical solvents.
Good temperature resistance up to 180°C.
Easy cake take off and releasing.
Good corrosion resistance for a longer service life.
Good Abrasive resistance .
Applications:
Sludge Dehydration.
Pulp squeezing in paper mills.
Food and juice squeezing.
Waste water treatments.
Paper and tissue plants.
Coal separating plants, etc
FGD Processing.
Belt Filter Press Specifications :
| Filtration Belt Specification | ||||||||
| Code | Thread Diameter(mm) | Density(threads/cm) | Tensile Strength(N/cm) | Thinkness(mm) | Air Permeability(m³/m²h) | |||
| warp | Weft | Warp | Weft | Surface | Joint | |||
| EDB-1 | 0.40 | 0.50 | 33 | 9 | 1600 | 900 | 0.8 | 1.30 |
| EDB-2 | 0.50 | 0.50 | 28 | 18.5 | 1600 | 900 | 1.20 | 1.5 |
| EDB-3 | 0.50 | 0.70 | 24 | 9 | 1600 | 650 | 1.23 | 1.90 |
| EDB-4 | 0.50 | 0.90 | 23 | 5.5 | 1600 | 900 | 1.40 | 1.90 |
| EDB-5 | 0.50 | 0.70 | 28 | 8.5 | 1600 | 900 | 1.53 | 2.0 |
| EDB-6 | 0.50 | 0.90 | 26.2 | 6.2 | 1600 | 900 | 1.49 | 2.15 |
| EDB-7 | 0.50 | 0.90 | 24.8 | 7.1 | 1600 | 900 | 1.48 | 2.0 |
| EDB-8 | 0.50 | 0.80 | 34.8 | 8 | 1600 | 900 | 1.40 | 2.1 |
| EDB-9 | 0.70 | 0.90 | 16.3 | 5 | 1600 | 900 | 1.50 | 2.1 |
| EDB-10 | 0.70 | 0.90 | 16.3 | 5.8/6 | 1600 | 900 | 1.70 | 2.1 |
| EDB-11 | 0.90 | 0.90 | 15.3 | 5 | 1600 | 900 | 2.10 | 2.77 |
| EDB-12 | 0.90 | 1.10 | 15.3 | 6.3 | 1600 | 900 | 2.45 | 2.85 |
| EDB-13 | 0.90 | 0.90 | 12.3 | 9.5 | 1600 | 900 | 2.20 | 3.5 |
Packing and delivery :
1. Bubble Film and waste thick fabric wrapping while protecting inside fabric.
2. Wrapped special fabric package outside. (Air shipping )
3. Composite wooden box(seashipping )
Our service :
1. Samples: free samples with detail specification for you to choose.
2. We will make the exact specifications as customer's requirements
3. Felt and fabric design solution will be provided within 24 hours By Technician Department.
4. There is a Strict quality control process during each production step. Ensuring the quality.
