Pulse Jet Dust Collector PPC-96-10
ECOGRACE
PPC502 Aluminum Melting Furnace Filter
Aluminum melting furnace Dust Collector,
High Temperature Flue Gas Suction Extraction System Air Polllution Control System Dust Dust Collector
Ecograce dust collection section wildly served for Leads , Copper, Aluminium Smelting plants.
The pulse jet type dust collector is an improved high-efficient model dust collector. It solves the problems like low intensity of dust-cleaning, and distribution of air flow, etc. With stable operation, easy maintenance and long life of filter bag, the dust collector for melting furnace is highly adopted by customers worldwide.
The filter bag of the dust collector equiped is polyester needle felt filter, it is suitable for the temperature continuous less than 120℃.
The filter bag made of METAMAX, Nomex, Aramid Felt is good for high temperature working temperature 204℃. The dust-collecting efficiency is more than 99.8%.
Applications:
The pulse type dust collector is taken for copper melting furnaces, aluminum casting furnaces, asphalt mixing plants, grinding machines, kiln dust and other dust collection and desulphurization systems.
Bag Filter Dust Collector Details:
1. ECOGRACE BAG FILTER DUST COLLECTOR, we designed the longer filters inside dust collector take smaller area which will increase the processing capacity, therefore it is more convenient for reconstruction.
2. We take seperate chamber off line dust cleaning in bag filter dust collector design, it is with high efficiency and few secondary dust stick. Meanwhile, it effectively save the energy. Our design effectively protect the filter bags and pulse valves, save the operation and maintenance cost for the dust collector system.
3. The filter bags will be replaced without stop the filtration system.
4. ECOGRACE Dust Collector Euiped with filter and cages on our own which are with good sealing, good tightness,easy installation.
5. We take Air leaking detection with oil so that keep air leaking <0.5%.
6. Our Bag Filter Dust Collector is controlled by PLC, it is with automatic dust cleaning, automatic temperature control and over temperature alarm.
ECOGRACE FILTER is SGS and ISO9001:2008 approved manufacturer of dust collector and filter matreirals with over 20 years expertise experience for providing dust filtration solutions.
Bag Filter Dust Collecotor Industrial Application:
Melting Furance, Aluminum, Copper, Leads,etc.
Asphalt Mixing, Batching, Blending opetions
Cement production
Powder processing
Steel meltingBattery Plants
Wood working.
Bag Filter Dust Collector Specification:
Model | PPC32-3 | PPC32-4 | 32-5 | 32-6 | 64-4 | 64-5 | 64-6 | 64-7 | 64-8 | |
Air volume (m3 /h) | 6900 | 8930 | 11160 | 13390 | 17800 | 22300 | 26700 | 31200 | 35700 | |
Total filter area (m2) | 93 | 124 | 155 | 186 | 248 | 310 | 372 | 434 | 496 | |
Chamber(pcs) | 3 | 4 | 5 | 6 | 4 | 5 | 6 | 7 | 8 | |
Quantity of filter bag(pcs) | 32 | 64 | ||||||||
Total quantity of filter bag(pcs) | 96 | 128 | 160 | 192 | 256 | 320 | 384 | 448 | 512 | |
Pulse valve | Quantity | 3 | 4 | 5 | 6 | 4 | 5 | 6 | 7 | 8 |
Specification | 1 | 2 | ||||||||
Specification of filter bag | 130(D.)*2450 | |||||||||
Filter material | Based on flue gas properties | |||||||||
Filtration speed | 0.8~2.0(Adjustable) | |||||||||
Negative pressure | less than 6000 | |||||||||
Resistance | 1470~1770 | |||||||||
Inlet dust concentration | less than 200 | less than 1000 | ||||||||
Blowing pressure | 0.5~0.7 | |||||||||
Compressed air consumption | 0.27 | 0.37 | 0.46 | 0.55 | 1.2 | 1.5 | 1.8 | 2.1 | 2.4 | |
Air-locking unit | Adjustable | |||||||||
Screw conveyor | No | Adjustable | ||||||||
Area of heat preservation | 26.5 | 34 | 41 | 48.5 | 70 | 94 | 118 | 142 | 176 | |
